AMS 5626 Turbine Steel Flat Bar

Product Categories
Mianyang Baoheng New Material Technology Co.,Ltd
Contact Now

AMS 5626 Turbine Steel Flat Bar

  • 1
  • 2
  • 3

Brand Name : PANGANGGROUP,TISCO,ANSTEEL,BAOSTEEL

Model Number : AMS 5626, AMS 5626D

Certification : SGS, TUV, BV, ISO, MTC

Place of Origin : China

MOQ : 1000kg

Price : Negotiations

Payment Terms : T/T

Supply Ability : 50000KGS/Month

Delivery Time : Ex-stock for delivery: 3-7 days Production lead time: 30-60 days

Packaging Details : Wooden Pallet BOX;Standard Seaworthy Package;based on the customer's special requirement

Characteristic : --

Heat treatment condition : +N, +AT, etc.

Processing methods : Hot Working, Machined, etc

Available Shapes : Length, Heavy, middle plate via hot rolled

Surface : Grinding, Centreless Ground, etc.

Application : Bolts and Nuts, Gears,

Material Category : Aerospace Material Steel Series

Contact Now

AMS 5626 Turbine Steel Flat Bar

Size Range

Round bar / Wire rod (Diameter): 3.0mm to 1000mm
Square bar / Flat bar: 3.0mm to 1000mm
Forging piece:

Stepped shafts with flanks/discs /tubes
/slugs /donuts /cubes /other different shapes based on OEM.
Heavy/middle plate via hot rolled: T5 - 300mm X W10 - 1500mm X L1000-11000mm

Sheet steel via cold rolled:

T0.5 - 5mm X W5 - 1000mm X L1000 - 1000mm

Steel strip via cold rolled:

T0.5 - 5.0mm X W5 - 180mm X L (or in coil form)
Length Fixed length or random length or based on the customer's special requirement.


Chemical Composition and standard

Grade

AMS 5626
standard SAE AMS 5626D-2000
Chemical Composition (weight%)

C(％): 0.65~0.80
Si(％): 0.20~0.40
Mn(％): 0.20~0.40
P(％)≤: 0.030
S(％)≤: 0.030
Cr(％): 3.75~4.50
Ni(％): --
Mo(％): ≤1.0

W(％): 17.24~18.75

V(%): 0.90~1.30


AMS 5626 Turbine Steel Flat Bar


Mechanical Properties

AMS 5626 Turbine Steel Mechanical Properties

Tensile strength, Rm/MPa: --
Yield strength, Rp/MPa: --
Elongation/%: --
Reduction of area, ψ/%: --
Impact, KV /J: --
Annealed hardness HB:

≤269
